Technical characteristics

Brand		VIGNAL
Product Type		Complete lamp
Voltage		24V
Source		LED
Max Current		Additional connector N° 1 position : 0.5A (15W max), Additional connector N° 2 position : 0.5A (15W max), Additional connector N° 3 reverse : 1A (35W max), Additional connector N° 4 flashing side marker : 0.5A (15W max)
Connector		AMP 1.5 - 7 pin rear connector
Mounting Direction		Horizontal
Side		Right
Lens Material		Polycarbonate
Shape		Rectangle
Fixation Bolt Distance		152 mm
Length		350 mm
Width		130 mm
Depth		40 mm
Main Functions		Dynamic indicator, Stop, Position, Reverse, Fog
Specific Functions		Additional connectors, BLACK EDITION black mask
IP protection		IP69K
EMC		E2 10R-0516057
ADR		ADR
ECE		E2 18042, ECE
Industry		Agriculture, Construction, Forestry, Handling and Forklifts, Mining, Trucks, Vans and Chassis cab
