TLP - TRIFLASH LED 500 AK5 Class 2

Ref. TRL.500 Show/hide other part numbers

Ref. D16001

Designed and manufactured in Europe, the Triflash 500 TRL.500 is a double-sided illuminated triangle of 500mm, Class 2, with bottom hinge mounting. This Triflash LED 12/24 Vdc has been designed for industrial vehicles in compliance with NF EN... Read more

Data Sheet

Homologation certificate

Not all products are available in all markets.

Need some advices ? Any questions ? We call you back !

Name *

Email *

Telephone *

Zip code *

Country *

* Mandatory fields

All data provided to us is only used by our services, as part of your call request and any commercial relationship that may result (learn more).

Technical characteristics Similar products

Technical characteristics

Brand		SESALY
Triflash size		500 (vehicle <3,5t)
Product Type		Triflash
Class		Class B (visible at 250 m)
Lift		Manual
Voltage		12/24 V
Consumption		9,5W
Approval		NF EN 12352, NF P 98475
Fixation		2 X M8 screws
Cable Length		6,5 m
Material		Fiber-filled polyamide, yellow color
Fixation Bolt Distance		150-160 mm
Depth		55 mm
Height		443 mm
Weight		2,40 Kg
Specific Functions		Double-action spring hinge (forward/backward)
Operation Temperatures		-30°C to +60°C
Warranty		2 years
EMC		ECE R10-06
Industry		Agriculture, Construction, Trucks, Vans and Chassis cab
